Move - Rotate - Scale - Mirror - Fillet - Offset

Under Menu -> Draw , you can find further edit command to manipulate CAD Entities.

This commands can affect only CAD Entities, they don't works with FAST SHAPE

This commands apply to selected entities


With the TRANSLATE or ROTATE operations , you can create linear or circular array of geometry.
